COMPOSITION:

• Metal sheet box, RAL 7035
• Door interlock switch disconnector
• Main fuses
• Three-phase impedance with Klixon
• 2 contactors
• Current transformer
• 400/24 V safety transformer for auxiliary circuit
• Electronic control card UNI EN-12845 with display 65x15
• Protective fuses for transformer, auxiliary circuit and electronic card
• Key selector switch 0-1 (automatic start mode)
• Terminal board
• 4 fixing brackets
• Instruction manual

TECHNICAL FEATURES:

• Power supply voltage 400 Vac ±10%
• Operating f requency 50/60 Hz
• Protection degree IP55
• Operating temperature -5/+40°C
